Inverex Veyron II 6KW Hybrid Solar Inverter

Save 4%

Price:
Rs.269,000 Rs.280,000

Description

  • Dual Output option with 6000W Inverter
  • Auto Synchronization With Inverex Lithium Battery
  • With Grid-Tie/Net Metering Option
  • No Zero Export Device Required
  • Optional Parallel Kit (Upto 9 Units)
  • Works Without Battery Directly On Solar
  • Built-in MPPT Solar Charger Upto 6500 Watts (120 Amp)
  • Built-In Anti-Dust Kit For Dust Protection
  • Communication Port For BMS Through (RS485, CAN-BUS, RS232)
  • Conformal Coating For PCB Protection From Humidity
  • Built-In BMS & SOC based battery control



 Model VEYRON II 6000-48
Rated Power 6000W
INPUT
Voltage 230 VAC
Selectable Voltage Range 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances)
Frequency Range 50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode) 170-280 VAC (For Personal Computers)
Overload capacity "5s@≥150% load; 10s@110%~150% load;
Efficiency (Peak) 90%
Transfer Time "10 ms (For Personal Computers) 20 ms (For Home Appliances)"
Waveform Pure sine wave
Dual Outputs Yes
BATTERY
Battery Voltage 48 VDC
Floating Charge Voltage 54 VDC
Overcharge Protection 66 VDC
SOLAR CHARGER & AC CHARGER
Solar Charger Type MPPT
Maximum PV Array Open Circuit Voltage 500 VDC
Maximum PV Array Power 6500W
MPP Range @ Operating Voltage 120~430 VDC
Maximum Solar Charge Current 120A
Maximum AC Charge Current 120A
Maximum Charge Current 120A
Maximum Solar Input Current 27A
PHYSICAL
Dimension, DXWXH (mm) 140 x 295 x468
Net Weight (kgs) 11.0
Communication Interface RS485, RS232, Optional for Wi-Fi (Built-in BMS)
OPERATING ENVIRONMENT
Humidity 5% to 95% Relative Humidity(Non-condensing)
Operating Temperature -10°C to 50°C
Storage Temperature -15°C to 60°C
