Dunext DN3-50KTL 50KW Three Phase IP65 On-Grid Inverter with Zero Export Device

Dunext DN3-50KTL 50KW Three Phase IP65 On-Grid Inverter with Zero Export Device

SKU: AR-002429
Product Type: solar inverter
Rs.495,000.00
Rs.510,000.00
Rs.495,000.00
Save Rs.15,000.00
Subtotal: Rs.495,000.00

5 Years Brands Replacement Warranty

Estimated Shipping Time: 48 to 72 Hours

You Have to Pay Full Payment in Advance for Order Confirmation

Full Advance Payment Required for Order Processing of Batteries, Inverters, And Structures.

Heavy weight parcels will be dispatch through Cargo Service

Customer will pay Cargo charges on delivery.

Dunext DN3-50KTL 50KW Three Phase IP65 On-Grid Inverter with Zero Export Device

Dunext DN3-50KTL 50KW Three Phase IP65 On-Grid Inverter with Zero Export Device

Rs.510,000.00 Rs.495,000.00
Dunext DN3-50KTL 50KW Three Phase IP65 On-Grid Inverter with Zero Export Device

Dunext DN3-50KTL 50KW Three Phase IP65 On-Grid Inverter with Zero Export Device

Rs.510,000.00 Rs.495,000.00
Description

Dunext DN3-50KTL 50KW Three Phase IP65 On-Grid Inverter

Reliable, efficient, and smart — the Dunext DN3-50KTL is the perfect solution for high-performance solar energy systems.

Designed for residential, commercial, and industrial applications, the Dunext DN3-50KTL offers superior performance with a maximum AC output power of 50,000W, making it ideal for maximizing solar energy harvest. With a wide MPPT voltage range of 180V to 1000V and support for 150% DC input oversizing, this three-phase inverter ensures exceptional flexibility and compatibility with modern PV arrays.

Key Features:

  • Max. PV Power: 75,000W — Ideal for large-scale PV installations.
  • Dual MPPT Design: 4 MPPT trackers for maximum efficiency and energy yield.
  • High Input Voltage: Supports up to 1100V with 600V rated input and 160V startup.
  • AC Output Power: 50,000W rated | 55,000VA max. apparent power.
  • Rated Voltage & Frequency: 3/N/PE, 220/380V or 230/400V | 50/60Hz.
  • Adjustable Power Factor: From 0.8 leading to 0.8 lagging.
  • Top Efficiency: Up to 98.8% max. and 98% European efficiency.
Max. Recommended PV Power [Wp] 30000
Max. PV Input Voltage [V] 1100
MPPT Voltage Range [V] 180 ~ 1000
Rated Input Voltage [V] 600
Start-Up Voltage [V] 200
No. of MPP Trackers 4
No. of Input Strings per Tracker 2 / 2 / 2 / 2
Max. PV Input Current [A] 40 / 40 / 40 / 40
Max. Short-Circult Current per MPPT [A] 50 / 50 / 50 / 50
AC Output
Rated AC Power [W] 50000
Max. Apparent Power [VA] 55000
Max. AC Current [A] 83.3
Rated AC Voltage [V] 3 / N / PE, 220 / 380, 230 / 400
Grid Frequency [Hz] 50 / 60
Adjustable Power Factor [cos φ] 0.8 leading ... 0.8 lagging
Output THDi [@Rated Output] < 3%
Efficiency
Max. Efficiency 98.8%
European Efficiency 98.0%
DC Insulation Monitoring Yes
Input Reverse Polarity Protection Yes
Anti-Island Protection Yes
Residual Current Monitoring Yes
AC Overcurrent Protection Yes
AC Short-Circuit Protection Yes
DC Surge Protection Yes (Type ll)
AC Surge Protection Yes (Type ll)
AFCI Protection Optional
PID Function Optional
DC Switch Yes
Dimension [W * H * D] [mm] 585 * 480 * 220
Weight [kg] 37
Display LED + OLED
Communication RS485 and USB (Standard), Wifi (Standard), 4G or Ethernet (Optional)
Ambient Temperature Range [℃] -25 ~ +60
Relative Humidity 0 ~ 100%
Operating Altitude [m] ≤ 2000
Standby Self Consumption [W] < 1
Topology Transformerless
Cooling Natural
Degree of Protection IP65
Noise [dB] < 45
Grid Connection Standards NB / T32004-2018,EN 50549-1, IEC 61727, IEC 62116
Safety Regulation IEC 62109-1, IEC 62109-2
EMC EN / IEC 61000-6-1,EN / IEC 61000-6-3
Natural cooling for mute operation IP65 outdoor design
Wider MPPT voltage range (140 ~ 1000V) 150% DC input oversizing
Remote firmware upgrade Built-in zero injection function
