Voltrra Falcon 8kW IP66 Hybrid Solar Inverter | Dual Output
Voltrra Falcon 8kW IP66 Hybrid Solar Inverter | Dual Output
Voltrra Falcon 8kW IP66 Hybrid Solar Inverter | Dual Output

Voltrra Falcon 8kW IP66 Hybrid Solar Inverter | Dual Output

Write A Review
SKU: AR-003547
Product Type: Hybrid Solar Inverter
Rs.285,000.00
Rs.295,000.00
Rs.285,000.00
Save Rs.10,000.00
Subtotal: Rs.285,000.00

3 Year Brand Warranty + 2 Year Service Warranty

Estimated Shipping Time: 48 to 72 Hours

You Have to Pay Partial Payment in Advance for Order Confirmation

Full Advance Payment Required for Order Processing of Batteries, Inverters, And Structures.

Heavy weight parcels will be dispatch through Cargo Service

Customer will pay Cargo charges on delivery.

Voltrra Falcon 8kW IP66 Hybrid Solar Inverter | Dual Output

Voltrra Falcon 8kW IP66 Hybrid Solar Inverter | Dual Output

Rs.295,000.00 Rs.285,000.00
Voltrra Falcon 8kW IP66 Hybrid Solar Inverter | Dual Output
Voltrra Falcon 8kW IP66 Hybrid Solar Inverter | Dual Output
Voltrra Falcon 8kW IP66 Hybrid Solar Inverter | Dual Output

Voltrra Falcon 8kW IP66 Hybrid Solar Inverter | Dual Output

Rs.295,000.00 Rs.285,000.00
Description

The Voltrra Falcon 8kW Hybrid Solar Inverter is a high-performance solar power solution designed for residential and commercial applications. With an 8kW rated output and up to 8.8kW load support, it efficiently manages demanding electrical loads while maximizing solar energy utilization. Built with IP66 protection, the Voltrra Falcon is designed to withstand dust and water exposure, making it suitable for challenging installation environments.

Key Features

8kW Rated Output – Supports loads up to 8.8kW for reliable power delivery.

12kW Maximum PV Input – Handles high solar PV capacity for greater energy generation.

3 Solar MPPTs – Optimizes solar production from multiple PV strings and panel orientations.

Dual Output – Enables flexible management of different electrical loads.

Battery & Batteryless Operation – Can operate with batteries or directly with solar/grid power, depending on system configuration.

IP66 Protection – Provides strong protection against dust and water for reliable outdoor installation.

Hybrid Solar Inverter – Suitable for residential, commercial, and backup power applications.

Specification Falcon 8kW
Rated Output Power 8kW
Maximum Apparent Output Power 8.8kVA
Maximum PV Input Power Up to 12kW
Number of MPPT Trackers 3
Strings per MPPT 2 / 1 / 2
Maximum PV Input Voltage 550V
PV Start-Up Voltage 100V
MPPT Voltage Range 100–430V
Rated PV Input Voltage 360V
Maximum Input Current per MPPT 16A
Maximum Short-Circuit Current per MPPT 24A
Battery Voltage 48V
Battery Voltage Range 40–58V
Battery Type Lithium-ion / Lead-acid
Maximum Charge/Discharge Power 8kW
Maximum Charge/Discharge Current 160A
Battery Communication CAN
Battery Charging Strategy Self-adaption to BMS
Rated Backup Voltage 230V
Rated Backup Frequency 50/60Hz
Backup Output Current 34.8A
Maximum Backup AC Current 38.3A
Peak Output Power 8.8kW
Backup Switch Time <20ms
Grid Voltage 230V
Grid Voltage Range 176–270V
Grid Frequency 50/60Hz
Grid Frequency Range 47–61Hz
Maximum Grid Passthrough Current 160A
Power Factor >1 (0.8 leading to 0.8 lagging)
THDi <3%
Grid Type L+N+PE
Operating Temperature -25°C to +60°C
Relative Humidity 0–95%, non-condensing
Operating Altitude 0–2,000m, derating above 2,000m
Protection Rating IP66
Topology Non-isolated
Surge Protection DC Type III / AC Type III
Cooling Fan Cooling
Noise Emission <55dB
Dimensions 486 × 231 × 530mm
Weight 25.8kg
Communication RS485 / CAN
Display LCD
PV Connection MC4
