UNI-T UT33A+ Palm Size Digital Multimeter with Auto range
UNI-T UT33A+ Palm Size Digital Multimeter with Auto range

UNI-T UT33A+ Palm Size Digital Multimeter with Auto range

SKU: AR-000198
Product Type: Multimeter
Rs.3,599.00
Rs.4,000.00
Rs.3,599.00
Save Rs.401.00
Subtotal: Rs.3,599.00
  • Alladin Store

7 Days Check Warranty

Estimated Shipping Time: 48 to 72 Hours

You Have to Pay Partial Payment in Advance for Order Confirmation

Full Advance Payment Required for Order Processing of Batteries, Inverters, And Structures.

Heavy weight parcels will be dispatch through Cargo Service

Customer will pay Cargo charges on delivery.

UNI-T UT33A+ Palm Size Digital Multimeter with Auto range

UNI-T UT33A+ Palm Size Digital Multimeter with Auto range

Rs.4,000.00 Rs.3,599.00
UNI-T UT33A+ Palm Size Digital Multimeter with Auto range
UNI-T UT33A+ Palm Size Digital Multimeter with Auto range

UNI-T UT33A+ Palm Size Digital Multimeter with Auto range

Rs.4,000.00 Rs.3,599.00
Description

● Clear LCD display

● Auto Range Selection

● Comfortable protective cover, with test lead hanging groove
● 2 meters drop test, precision protection
● Loud buzzer sound; Ergonomic design

Specifications of UT33+ Series Palm Size Multimeters


Specifications Range UT33A+ UT33B+ UT33C+ UT33D+
DC voltage (V) 200mV/2V/20V/200V/600V ±(0.5%＋2) ±(0.5%＋2) ±(0.5%＋2) ±(0.5%＋2)
AC voltage (V) 600V ±(0.7%+3)
200V/600V ±(1.2%+3) ±(1.2%+3) ±(1.2%+3)
DC current (A) 10A ±(1%+2)
200μA/200mA/10A ±(1%+2)
2000μA/20mA/200mA/10A ±(1%+2) ±(1%+2)
AC current (A) 10A ±(1.2%+3)
Resistance (Ω) 200Ω/2kΩ/20kΩ/200kΩ
/2MΩ/20MΩ/200MΩ		 ±(0.8%+2)
200Ω/2kΩ/20kΩ
/200kΩ/20MΩ/200MΩ		 ±(0.8%+2)
200Ω/2kΩ/20kΩ
/200kΩ/20MΩ		 ±(0.8%+2) ±(0.8%+2)
Capacitance (F) 2mF ±(4%+8)
Temperature -40℃~1000℃ ±(1%+4)
-40℉~1832℉ ±(1.5%+5)
Features
Display count 2000 2000 2000 2000
Auto power off/Auto backlight off √ √ √ √
Diode test/Continuity buzzer √ √ √ √
2m drop test/ Test probe holder √ √ √ √
Range selection Auto Manual Manual Manual
Battery test 1.5V/9V/12V
NCV √
General Characteristics
Power 1.5V battery (R03) x 2
Display 66mm x 51mm
Product net weight Red and grey
Product color 206g (batteries included)
Product size 134mm x 77mm x 47mm
Standard accessories Batteries, test leads, K-type thermocouple (UT33C+)
Standard individual packing Gift box, English manual
Standard quantity per carton 60pcs
Standard carton measurement 640mm x 310mm x 350mm
Standard carton gross weight UT33A+: 18.6kg; UT33B+: 19.4kg; UT33C+: 20.6kg; UT33D+: 19.8kg
