PRIMAX FOTON 8.0 8kw Hybrid Solar Inverter 24V | Single MPPT

PRIMAX FOTON 8.0 8kw Hybrid Solar Inverter 24V | Single MPPT

Write A Review
SKU: AR-003368
Product Type: Hybrid Solar Inverter
Rs.125,000.00
Rs.135,000.00
Rs.125,000.00
Save Rs.10,000.00
Subtotal: Rs.125,000.00

2 year parts + 3 year service warranty

Estimated Shipping Time: 48 to 72 Hours

You Have to Pay Partial Payment in Advance for Order Confirmation

Full Advance Payment Required for Order Processing of Batteries, Inverters, And Structures.

Heavy weight parcels will be dispatch through Cargo Service

Customer will pay Cargo charges on delivery.

PRIMAX FOTON 8.0 8kw Hybrid Solar Inverter 24V | Single MPPT

PRIMAX FOTON 8.0 8kw Hybrid Solar Inverter 24V | Single MPPT

Rs.135,000.00 Rs.125,000.00
PRIMAX FOTON 8.0 8kw Hybrid Solar Inverter 24V | Single MPPT

PRIMAX FOTON 8.0 8kw Hybrid Solar Inverter 24V | Single MPPT

Rs.135,000.00 Rs.125,000.00
Description

The PRIMAX FOTON 8.0 Hybrid Solar Inverter is a high-performance single-phase inverter designed to deliver reliable power for residential and small commercial solar systems. Supporting up to 8000W PV input, 24V battery systems, and Pure Sine Wave output, it ensures efficient energy conversion with up to 98% DC/AC efficiency. Equipped with Single MPPT technology, WiFi monitoring support, BMS communication, and the ability to operate with or without batteries, the FOTON 8.0 provides intelligent energy management, stable backup power, and seamless solar integration.

Key Features

8000W Maximum Solar PV Input

24V Battery System with 120A Solar Charging

Pure Sine Wave Output for Sensitive Electronics

Single MPPT Technology (60–500VDC)

Supports Lithium Batteries with BMS Communication

Operates With or Without Battery

Dual Output for Main & Secondary Loads

WiFi Monitoring & Remote Configuration Support

Fast UPS Transfer Time (10ms)

High DC/AC Efficiency up to 98%

Parameter / Property Value / Specification
Brand PRIMAX Solar Energy
Model FOTON 8.0
Type Hybrid Solar Inverter
Phase Single Phase
Nominal Voltage 220/230/240VAC
Input Voltage Range 90–280VAC ±3V (Normal Mode) / 170–280VAC ±3V (UPS Mode)
Input Frequency Range 50Hz / 60Hz (Adaptive)
Rated Power 4500W
PV Mode / AC Mode Power 4500W
Battery Mode Power 4000W
Output Voltage (AC) 220/230/240VAC ±5%
Output Frequency 50/60Hz ±0.1%
Dual Output Rated Power Main Load: 4000W, Second Load: 4000W
Output Waveform Pure Sine Wave
Transfer Time (Adjustable) 10ms (Computer), 20ms (Home Appliances)
Peak Power 8000VA
Overload Capacity (Battery Mode) 105%–150% Load: 11s; 150%–200% Load: 2s; >200% Load: 400ms
Peak Efficiency (Battery Mode) >94%
Grid-Tie Output Voltage 220/230/240VAC
Feed-in Grid Voltage 175–265VAC
Feed-in Grid Frequency Range 49–51±1Hz / 59–61±1Hz
Rated Feed-in Grid Current 17.4A
Peak Efficiency (DC/AC) 98%
Battery Rated Voltage 24VDC
Constant Voltage Charging Voltage 28.2VDC (Adjustable)
Floating Charge Voltage 27VDC (Adjustable)
PV Charging Method Single MPPT
PV Max Input Power 8000W
MPPT Tracking Range 60–500VDC
Best PV Voltage Range 300–400VDC
Max PV Input Voltage 500VDC
Max PV Input Current 32A
Max PV Charging Current 120A
Max AC Charging Current 100A
RS232 Port External WiFi Device / Monitoring & Firmware Update
RS485 Port BMS Communication
Dry Contact Port Supports Generator Auto-Start Signal
Parallel Function No
Operating Temperature -10°C to 50°C
Operating Humidity 20%–95% (Non-condensing)
Storage Temperature -15°C to 60°C
Operating Altitude Up to 1000m (Derating required above 1000m, max 4000m)
Noise Level ≤50dB
Certifications IEC 62109-1, IEC 62109-2, IEC 61683
