MORA 6IN1 din rail AC 220V 100A Voltage Current KWH Electric energy meter with Frequency and Power Factor

Save 13%

Rs.3,050 Rs.3,500


Mora 6 in 1 Meter Voltage Display Ampere Display Power Factor Display Kwh Reading Power Display Frequency Meter

  • Measurement accuracy: 1%±2 words
  • Measuring range: AC voltage AC40-300V(110V 220V use), AC200-450V(380V 450V use)
  • Alternating current: AC0-100A, current display resolution is 0.01A
  • Power frequency: 45Hz-65Hz
  • Power factor: 0.00-1.00PF
  • Active power: the measurement range is 0-45000W, the display resolution between 0-9999.9W is 0.1W, and the rest is 1W
  • Electricity: the measurement range is 0-99999kwh, the minimum display resolution of 0-999.99kwh is 0.01kwh
  • 1000.0-9999.9kwh minimum display resolution is 0.1kwh
  • The minimum resolution of 10000.0-99999kwh is 1kwh
  • Measuring speed: about 2 times per second
  • Dimensions: 54*80*64mm
  • Installation method: rail type


Ask a Question
  • Can we count our total units with record

    Yes , it show total units . You can reset units any time.

  • Hm baki seting ko change kar saktay hai kia

    Dear Sir , Is me sirf reading ko reset kr skty han. KWH(units) ki value zero ho jye gi sirf.
