MaxPower PV Tech 1200 Single Phase Hybrid Solar Inverter 1.2kW | 60A MPPT | 12V Battery | Pure Sine Wave

MaxPower PV Tech 1200 Single Phase Hybrid Solar Inverter 1.2kW | 60A MPPT | 12V Battery | Pure Sine Wave

SKU: AR-003079
Product Type: hybrid inverter
Rs.46,000.00
Rs.50,000.00
Rs.46,000.00
Save Rs.4,000.00
Subtotal: Rs.46,000.00

5 years warranty

Estimated Shipping Time: 48 to 72 Hours

You Have to Pay Partial Payment in Advance for Order Confirmation

Full Advance Payment Required for Order Processing of Batteries, Inverters, And Structures.

Heavy weight parcels will be dispatch through Cargo Service

Customer will pay Cargo charges on delivery.

MaxPower PV Tech 1200 Single Phase Hybrid Solar Inverter 1.2kW | 60A MPPT | 12V Battery | Pure Sine Wave

MaxPower PV Tech 1200 Single Phase Hybrid Solar Inverter 1.2kW | 60A MPPT | 12V Battery | Pure Sine Wave

Rs.50,000.00 Rs.46,000.00
MaxPower PV Tech 1200 Single Phase Hybrid Solar Inverter 1.2kW | 60A MPPT | 12V Battery | Pure Sine Wave

MaxPower PV Tech 1200 Single Phase Hybrid Solar Inverter 1.2kW | 60A MPPT | 12V Battery | Pure Sine Wave

Rs.50,000.00 Rs.46,000.00
Description

The MaxPower PV Tech 1200 Single Phase Hybrid Inverter is a compact and efficient 1.2kW solar power solution designed for residential and small backup systems. Equipped with a built-in 60A MPPT solar charger, this inverter efficiently converts solar energy and delivers stable power for your home appliances. With a wide PV input voltage range of 18–125V and support for up to 1000W solar input, the PV Tech 1200 maximizes solar energy utilization. The inverter produces a pure sine wave output, ensuring safe and stable operation for sensitive electronics such as computers, televisions, routers, and other household devices.

Key Features

1.2kW Rated Output Power – Ideal for small solar systems and home backup power.

Built-in 60A MPPT Solar Charger – Maximizes solar energy harvesting efficiency.

Wide PV Input Voltage Range (18–125V) – Supports flexible solar panel configurations.

Pure Sine Wave Output – Safe for sensitive electronics and appliances.

Supports Lithium-ion & Lead-acid Batteries – Compatible with modern battery technologies.

Lithium Battery Activation – Easy integration with lithium battery systems.

Fast Transfer Time (10ms) – Ensures seamless switching during power outages.

LED Display Interface – Simple monitoring of system performance.

Detachable Dust Cover – Protects internal components from dust.

Compact & Lightweight Design – Easy installation for home solar setups.

Specification Details
Model PV Tech 1200
AC Input Voltage 208 / 220 / 230 / 240 VAC (L + N + PE)
Voltage Range 90–280±3 VAC (Normal Mode), 170–280±3 VAC (UPS Mode)
Frequency 50/60Hz Auto Adaptive
Rated Output Capacity 1.2 kW
Surge Power 2.4 kVA
Output Voltage 208 / 220 / 230 / 240 VAC
Power Factor 1.0
Transfer Time 10 ms
Waveform Pure Sine Wave
Maximum Efficiency 90% @ 12VDC
Solar Charger Type MPPT
Max PV Input Power 1000 W
Max PV Input Current 12 A
MPPT Voltage Range 18–100 VDC
Max PV Open Circuit Voltage 125 VDC
Max PV Charge Current 60 A
Max AC Charge Current 60 A
Max Total Charge Current 120 A
Battery Voltage 12 VDC
Floating Charge Voltage 13.8 VDC
Overcharge Protection 15 VDC
Battery Type Lithium-ion / Lead-acid
Display LCD
Communication RS232 / RS485
IP Rating IP21
Operating Temperature -10°C to 60°C
Storage Temperature -15°C to 60°C
Humidity 5% – 95% (Non-condensing)
Net Weight 3.2 kg
Dimensions (W × H × D) 347 × 236 × 91 mm
Max Operating Altitude 4000 m (Derating above 1000 m)
Activation AC & PV Activation Supported
