Knox Zynex ZX-3M-1020 | 10kW IP66 Hybrid Solar Inverter With PV 20000W 3 MPPT, Wi-Fi - IP66

Knox Zynex ZX-3M-1020 | 10kW IP66 Hybrid Solar Inverter With PV 20000W 3 MPPT, Wi-Fi - IP66

SKU: AR-002625
Product Type: solar inverter

Best Price Guarranted

At Alladin.pk, we don’t just match prices—we beat them while maintaining top quality!

Rs.430,000.00
Rs.470,000.00
Rs.430,000.00
Save Rs.40,000.00
Subtotal: Rs.430,000.00
  • Alladin Store

5 Years Replacement Warranty

Estimated Shipping Time: 48 to 72 Hours

You Have to Pay Full Payment in Advance for Order Confirmation

Full Advance Payment Required for Order Processing of Batteries, Inverters, And Structures.

Heavy weight parcels will be dispatch through Cargo Service

Customer will pay Cargo charges on delivery.

Knox Zynex ZX-3M-1020 | 10kW IP66 Hybrid Solar Inverter With PV 20000W 3 MPPT, Wi-Fi - IP66

Knox Zynex ZX-3M-1020 | 10kW IP66 Hybrid Solar Inverter With PV 20000W 3 MPPT, Wi-Fi - IP66

Rs.470,000.00 Rs.430,000.00
Knox Zynex ZX-3M-1020 | 10kW IP66 Hybrid Solar Inverter With PV 20000W 3 MPPT, Wi-Fi - IP66

Knox Zynex ZX-3M-1020 | 10kW IP66 Hybrid Solar Inverter With PV 20000W 3 MPPT, Wi-Fi - IP66

Rs.470,000.00 Rs.430,000.00
Description

The Zynex 10kW Hybrid Inverter (ZX-3M-1020) delivers powerful performance for larger PV systems. With a 20kW max PV array capacity, robust 3 MPPT design, and intelligent hybrid operation, it ensures reliable energy storage, grid support, and backup power.

  • 3 Independent MPPTs – Flexible PV array design for higher yields
  • Max. 20A Input Current per MPPT – Ideal for bifacial & large-area solar modules
  • Up to 200% PV Oversizing – Maximize energy generation
  • UPS-Level Switching (<10ms) – Instant backup during power outages
  • Expandable up to 30kW – Scalable for future growth
  • Compatible with Lithium & Lead-Acid Batteries – Flexible storage options
  • Multi-Source Black Start – Integrates PV, battery, and generator for reliable restarts
  • IP66 Rated – Built tough for both indoor and outdoor installations

Download Datasheet

Technical Specifications:

Specification ZX-3M-1020 (10kW)
Max. PV Array Power 20,000 W
Max. Input Voltage 550 V
MPPTs / Strings per MPPT 3 / 1
Max. Input Current (per MPPT) 20 A
Battery Voltage Range 40–60 V
Max. Charge/Discharge Power 10,000 W
Max. Charge/Discharge Current 210 A
Battery Type Lithium (LiFePO₄) / Lead-acid
Rated AC Output Power 10,000 VA
Max. AC Output Power 11,000 VA
Efficiency (Max. / European) 97.6% / 97%
Switching Time <10 ms
Degree of Protection IP66
Dimensions (W × H × D) 484 × 679 × 230 mm
Weight 34.5 kg
