Knox Krypton 6000 4KW Hybrid Solar Inverter With PV 6000

Knox Krypton 6000 4KW Hybrid Solar Inverter With PV 6000

SKU: AR-002353
Product Type: solar inverter
Rs.118,000.00
Rs.155,000.00
Rs.118,000.00
Save Rs.37,000.00
Subtotal: Rs.118,000.00

1 Year Complete + 10 Year's Service Warranty

Estimated Shipping Time: 48 to 72 Hours

You Have to Pay Full Payment in Advance for Order Confirmation

Full Advance Payment Required for Order Processing of Batteries, Inverters, And Structures.

Heavy weight parcels will be dispatch through Cargo Service

Customer will pay Cargo charges on delivery.

Knox Krypton 6000 4KW Hybrid Solar Inverter With PV 6000

Knox Krypton 6000 4KW Hybrid Solar Inverter With PV 6000

Rs.155,000.00 Rs.118,000.00
Knox Krypton 6000 4KW Hybrid Solar Inverter With PV 6000

Knox Krypton 6000 4KW Hybrid Solar Inverter With PV 6000

Rs.155,000.00 Rs.118,000.00
Description

Power your home or business with the KNOX Krypton 6000, a 4kW-rated hybrid solar inverter designed for both grid-tie and off-grid applications. It supports up to 6000W of solar PV input, operates on a 24V battery system, and delivers pure sine wave AC output at high efficiency—ideal for sensitive electronics and demanding loads.

Key Features:

  • 4kW rated output with 6000W maximum PV input power
  • Hybrid functionality: Supports grid-tie and off-grid operations
  • Advanced MPPT solar charger with 120A maximum charging current
  • High efficiency: 95% DC/AC conversion
  • Pure sine wave output for compatibility with sensitive devices
  • Operating temperature range: -10°C to 50°C

Technical Specifications

KNOX Krypton 6000 Specifications
Model 4kW-24-PV 6000-T W/N
Phase Single Phase
Maximum PV Input Power 6000W
Rated Output Power 4000W
Battery + PV Output Power 4000W
GRID-TIE OPERATION
Nominal DC Voltage / Maximum DC Voltage 500 VDC
Start-up Voltage / Initial Feeding Voltage 120 VDC / 60 VDC
MPPT Voltage Range 60-450 VDC
Number of MPP Trackers / Maximum Input Current 1 / 30A (Max 40A)
Nominal Output Voltage (AC) 220 / 230 / 240 VAC
Output Voltage Range 90-280 VAC (For Personal Computers); 180-280 VAC (For Home Appliances)
Nominal Output Current 17.4A
Power Factor >0.99
Maximum Conversion Efficiency (DC/AC) 95%
OFF-GRID OPERATION
AC Start-up Voltage / Auto Restart Voltage 120-140 VAC / 180 VAC
Acceptable Input Voltage Range 90-280 VAC or 170-280 VAC
Frequency Range 50 Hz / 60 Hz (Auto-sensing)
Nominal Output Voltage (Battery Mode) 230 VAC
Output Waveform Pure Sine Wave
Efficiency (DC to AC) 80%
Transfer Time 10 ms (For Personal Computers); 20 ms (For Home Appliances)
BATTERY & CHARGER
Nominal DC Voltage 24 VDC
Floating Charge Voltage 27 VDC
Overcharge Protection 32 VDC
Solar Charger Type MPPT
Maximum Solar Charging Current 120A
Maximum AC Charging Current 120A
Maximum Charging Current 120A
Surge Power 9000 VA
GENERAL
Dimensions (D x W x H) 119 x 313.6 x 457.5 mm
Net Weight Not specified
Communication Ports USB / RS232 / RS485 / WiFi / Dry-contact
Humidity 0-90% RH (Non-condensing)
Operating Temperature -10°C to 50°C
Storage Temperature -15°C to 60°C
Certifications IEC 61683, IEC 62109-1, IEC 62109-2
