Jolta JBW242400N 25.6V 100Ah (2.56 kWh) LiFePO4 Lithium Battery – Wall Mount

Jolta JBW242400N 25.6V 100Ah (2.56 kWh) LiFePO4 Lithium Battery – Wall Mount

SKU: AR-002620
Product Type: Battery
Rs.135,000.00
Rs.149,999.00
Rs.135,000.00
Save Rs.14,999.00
Subtotal: Rs.135,000.00
  • Alladin Store

5 Years Component Replacement Warranty

Estimated Shipping Time: 48 to 72 Hours

You Have to Pay Partial Payment in Advance for Order Confirmation

Full Advance Payment Required for Order Processing of Batteries, Inverters, And Structures.

Heavy weight parcels will be dispatch through Cargo Service

Customer will pay Cargo charges on delivery.

Jolta JBW242400N 25.6V 100Ah (2.56 kWh) LiFePO4 Lithium Battery – Wall Mount

Jolta JBW242400N 25.6V 100Ah (2.56 kWh) LiFePO4 Lithium Battery – Wall Mount

Rs.149,999.00 Rs.135,000.00
Jolta JBW242400N 25.6V 100Ah (2.56 kWh) LiFePO4 Lithium Battery – Wall Mount

Jolta JBW242400N 25.6V 100Ah (2.56 kWh) LiFePO4 Lithium Battery – Wall Mount

Rs.149,999.00 Rs.135,000.00
Description

Upgrade your power storage with this high-performance JBW242400N 25.6V 100Ah Lithium Iron Phosphate (LiFePO4) Battery, designed for reliability, long life, and consistent energy output. Ideal for solar systems, backup power, RVs, marine, and industrial applications.

Key Features:

  • High Capacity & Energy: 100Ah capacity with a total energy of 2.56kWh.
  • Efficient Performance: Continuous charge & discharge up to 100A.
  • Long Lifespan: Projected calendar life of 10+ years with 80% recommended discharge depth.
  • Versatile Use: Supports parallel connection (series option available).
  • Safe & Reliable: Low self-discharge (2–3%/month) and stable operation from -10°C to 60°C.

Download Datasheet

Model  JB484800N
Performance
Voltage (Nominal) 25.6 V
Maximum Charge Voltage 28.8 V
Discharge Cut-Off Voltage 20.8 V (Configurable)
Total Energy 2560 Wh
Total Current 100 A
Continuous Discharge Current 50 A
Continuous Charge Rate 50 A
Cut-Off Current 2 A
ESR/AC @ 1 kHz < 10 mΩ
Physical Specifications
Weight 30 kg (Module) – 33 kg (With Pack)
Module Casing Material MS/Aluminum
Terminal Type Anderson
Dimensions (L × W × H) Module 350× 550 × 160 mm
Dimensions (L × W × H) Pack 400 × 600 × 210 mm
Features Jolta Battery; Alarm for under/over voltage, over current, out-of-range temperature
Compatible Inverters Pylontech, Victron Energy, Growatt, Deye, Solis, Maxpower, SolarMax, Inverex
Service Life
Projected Calendar Life ≥ 10 years
Shelf Life 5 Years
Safety & Environment
Over/Under Voltage Unit shut down
Over Current Unit shut down
Over Temperature Unit shut down
Cell Operating Temperature -10°C to 60°C
Operating Humidity Non-condensing
Additional
Parallel Connection Yes
Series Connection Custom Option
Self-Discharge 2–3% / month
Recommended Discharge Depth 80%
