Description

Itel IPL-51100 LiFePO₄ Lithium Battery 51.2V 100Ah – 5.12kWh

The IPL-51100 is a high-performance lithium iron phosphate (LiFePO₄) battery designed for solar energy storage systems. With a nominal voltage of 51.2V and 5.12kWh energy capacity, it offers reliable power backup for residential, commercial, and industrial applications. It features a robust build, long cycle life, and smart communication options for seamless system integration.

Key Features

  • High Energy Storage: 100Ah capacity with 5.12kWh of energy, perfect for demanding energy storage needs.

  • Safe & Reliable Chemistry: LiFePO₄ technology offers superior thermal and chemical stability for enhanced safety.

  • Smart Communication: Integrated RS485, CAN, and RS232 ports ensure easy communication with inverters and BMS systems.

  • Heavy-Duty Discharge Support: Delivers 100A continuous and 150A pulse discharge to handle high-demand loads.

  • Long Cycle Life: Offers over 6000 cycles with 10 years of design life under recommended usage conditions.

  • Expandable System: Can be connected in parallel with up to 15 batteries for scalable storage solutions.

  • Durable Construction: Sturdy metal casing with natural cooling and IP20 protection for dependable performance.

  • Built-in Protection Features: Includes current limiting, precharge, and intelligent voltage cut-offs to protect the battery and connected systems.

Specifications Table

Specification IPL-51100
Battery Type LiFePO₄
Nominal Voltage 51.2V
Nominal Energy 5.12kWh
Nominal Capacity 100Ah
Operating Voltage Range 40V–58.4V
Standard Charging Current 50A
Maximum Continuous Charge Current 100A
Cut-Off Charging Voltage 58.4V
Cut-Off Charging Current 2A
Standard Discharging Current 100A
Maximum Continuous Discharge Current 100A
Maximum Pulse Discharge Current 150A
Cut-Off Discharge Voltage 40V
Cut-Off Discharge Current 2A
Dimensions (D × W × H) 450 × 510 × 153 mm
Weight 50 kg
Communication Port RS485 / CAN / RS232
Parallel Connection Support Up to 15 Units
Working Temperature (Charging) 0°C to 55°C
Working Temperature (Discharging) -20°C to 60°C
Ingress Protection Rating IP20
Cooling Type Natural Cooling
Operating Humidity 10% to 95%
Maximum Altitude 2000 meters
Shell Material Metal
Current Limiting Function 10A
Precharge Function Enabled
Display Type LED
Design Life 10 Years
Cycle Life >6000 Cycles @25°C, 0.5C, 80%DOD
Certifications IEC62619 / UN38.3 / MSDS / DGM
