Itel 16kWh 51.2V 314Ah LiFePO4 Lithium Battery IP20

Itel 16kWh 51.2V 314Ah LiFePO4 Lithium Battery IP20

Write A Review
SKU: AR-003746
Product Type: lithium battery
Rs.569,000.00
Rs.610,000.00
Rs.569,000.00
Save Rs.41,000.00
Subtotal: Rs.569,000.00

5 Years Warranty

Estimated Shipping Time: 48 to 72 Hours

You Have to Pay Partial Payment in Advance for Order Confirmation

Full Advance Payment Required for Order Processing of Batteries, Inverters, And Structures.

Heavy weight parcels will be dispatch through Cargo Service

Customer will pay Cargo charges on delivery.

Itel 16kWh 51.2V 314Ah LiFePO4 Lithium Battery IP20

Itel 16kWh 51.2V 314Ah LiFePO4 Lithium Battery IP20

Rs.610,000.00 Rs.569,000.00
Itel 16kWh 51.2V 314Ah LiFePO4 Lithium Battery IP20

Itel 16kWh 51.2V 314Ah LiFePO4 Lithium Battery IP20

Rs.610,000.00 Rs.569,000.00
Description

The Itel 16kWh 51.2V 314Ah Lithium Battery is a high-capacity energy storage solution designed for residential and commercial solar power systems, hybrid inverters, and reliable backup power applications. Featuring advanced Lithium Iron Phosphate (LiFePO4) battery technology, it delivers efficient energy storage, stable performance, and a long service life. With a nominal energy capacity of 16kWh, a nominal voltage of 51.2V, and a maximum discharge power of 16kW, this battery is suitable for demanding energy storage requirements. It supports up to 32 units in parallel, allowing flexible system expansion as your power needs grow. The Itel lithium battery offers over 6,000 charge and discharge cycles under specified test conditions, helping provide long-term energy storage performance. Its integrated CAN 2.0 and RS485 communication interfaces support compatibility with suitable inverter and energy management systems.

Key Features

  • 16kWh Energy Capacity: Stores substantial energy for residential and commercial solar systems.

  • 51.2V Nominal Voltage: Designed for compatible low-voltage battery and inverter systems.

  • 314Ah Battery Capacity: Provides high-capacity energy storage for demanding applications.

  • LiFePO4 Battery Technology: Offers stable performance, enhanced thermal stability, and long cycle life.

  • Up to 16kW Discharge Power: Supports high-power applications when used within the system's specifications.

  • Over 6,000 Charge Cycles: Delivers long-term performance under specified laboratory test conditions.

  • Up to 32 Units in Parallel: Allows battery capacity to be expanded for larger energy storage systems.

  • CAN 2.0 and RS485 Communication: Enables communication with compatible inverters and monitoring systems.

  • 90% Recommended Depth of Discharge: Supports effective utilization of stored energy according to recommended operating guidelines.

  • IP20 Protection Rating: Intended for suitable indoor installation environments protected from water and excessive dust.

Technical Specifications

Specification Details
Brand Itel
Product Type Lithium Solar Battery
Battery Chemistry LiFePO4 (Lithium Iron Phosphate)
Nominal Energy 16kWh
Nominal Voltage 51.2V
Nominal Capacity 314Ah
Operating Voltage Range 43.2–57.6V
Maximum Continuous Charge Current 157A
Peak Charge Current 175A for 1 second
Maximum Continuous Discharge Current 157A
Peak Discharge Current 175A for 3 seconds
Maximum Discharge Power 16kW
Recommended Depth of Discharge 90%
Cycle Life Over 6,000 cycles under specified test conditions
Cycle Life Test Conditions 0.5C charge/discharge, 80% DOD, 80% EOL, at 25°C
Maximum Parallel Units 32
Communication Interfaces CAN 2.0 / RS485
Protection Rating IP20
Dimensions (D × W × H) 230 × 548 × 840 mm
Net Weight 120kg
Charging Temperature 0°C to +60°C
Discharging Temperature -20°C to +60°C
Recommended Operating Temperature +15°C to +35°C
Storage Temperature 0°C to +35°C
