Description

GoodWe Lynx A G3 Low Voltage Lithium Battery – Scalable Energy Storage Solution for Homes

The GoodWe Lynx A G3 Series is a low-voltage lithium battery system built on reliable Lithium Iron Phosphate (LFP) cell technology. Designed specifically for residential use, it delivers dependable solar backup and optimizes energy self-consumption. With a high energy density, compact design, and seamless expandability, it provides homeowners with a flexible, long-lasting storage solution. Each unit features an integrated Battery Management System (BMS) and supports up to 30 units in parallel, scaling capacity up to 150kWh. The system is compatible with GoodWe residential storage inverters, ensuring smooth integration and performance.

Key Features

  • Reliable LFP Cell Technology
    Equipped with Lithium Iron Phosphate (LFP) cells for enhanced safety, stability, and long-term performance.

  • Long Battery Life
    Supports over 6000 charge/discharge cycles with 70% end-of-life (EOL) capacity, ensuring years of dependable use.

  • Scalable System Capacity
    Connect up to 30 battery units in parallel, supporting a total system capacity of up to 150kWh to meet growing energy demands.

  • High Discharge Capability
    Delivers a continuous discharge current of up to 150A, suitable for heavy residential loads.

  • Built-in Battery Management System (BMS)
    Each battery pack includes a dedicated BMS for real-time monitoring, safety, and performance optimization.

  • Remote Diagnosis & Firmware Updates
    Enables remote diagnostics and software updates via compatible GoodWe inverters, reducing maintenance hassle.

  • Flexible Installation Options
    Supports various parallel connection types including hand-to-hand, busbar, and combiner box setups, allowing for installation versatility.

  • Compact & Lightweight Design
    Space-saving form factor makes it easy to transport and install in tight residential areas.

  • Full Compatibility
    Seamlessly integrates with GoodWe residential hybrid/storage inverters, ensuring system-wide compatibility and efficiency.

Technical Specifications

Specification LX A5.0-30
Nominal Battery Energy (kWh) 5.12
Usable Energy (kWh)*1 5
Cell Type LFP (LiFePO4)
Operating Voltage Range (V) 43.20 ~ 58.24
Nominal Charge Current (A)*2 60
Max. Continuous Charge Current (A)*2*3 90
Nominal Discharge Current (A)*2 100
Max. Continuous Discharge Current (A)*2*3 150
Max. Pulse Discharging Current (A)*2*3 <200 (30s)
Max. Continuous Discharging Power (W)*2*3 7200
Communication CAN
Operating Temperature (°C) Charge: 0<T≤55 | Discharge: -20<T≤55
Max. Storage Time 12 Months (maintenance-free)
Max. Operating Altitude (m) 4000
Weight (kg) 44
Dimensions (W × H × D mm) 442 × 133 × 520 (Core) / 483 × 133 × 559 (Max)
Ingress Protection Rating IP20
Applications On Grid / On Grid + Backup / Off Grid
Scalability Max. 30 in Parallel (150kWh) (Hand to hand / Combiner box / Busbar)
Mounting Method 19-inch rack / Floor-Mounted / Wall-Mounted
Round-trip Efficiency*1 ≥96%
Cycle Life 6000@25 ± 2°C 0.2C 70%EOL
Safety IEC62619, IEC63056, N140
EMC EN IEC 61000-6-1, -6-2, -6-3, -6-4
Transportation UN38.3, ADR
Environment ROHS
