CNC YC9VA-3 4Pole 3 Phase Voltage And Current Protector
CNC YC9VA-3 4Pole 3 Phase Voltage And Current Protector

CNC YC9VA-3 4Pole 3 Phase Voltage And Current Protector

SKU: AR-001267
Availability: In Stock
Product Type: voltage protector
Rs.9,900.00
Rs.9,999.00
Rs.9,900.00
Save Rs.99.00
Ampere: 63A
Subtotal: Rs.9,900.00
  • Alladin Store

Shipping

You have to pay Partial Payment for order confirmation

Shipped Within 2 - 5 Bussiness Days

CNC YC9VA-3 4Pole 3 Phase Voltage And Current Protector

CNC YC9VA-3 4Pole 3 Phase Voltage And Current Protector

Rs.9,999.00 Rs.9,900.00
CNC YC9VA-3 4Pole 3 Phase Voltage And Current Protector
CNC YC9VA-3 4Pole 3 Phase Voltage And Current Protector

CNC YC9VA-3 4Pole 3 Phase Voltage And Current Protector

Rs.9,999.00 Rs.9,900.00
Ampere: 63A
Description

CNC YC9VA-3 4Pole 3 Phase Voltage and Current Protector

The CNC YC9VA-3 4Pole 3 Phase Voltage and Current Protector is designed to safeguard electrical systems by offering comprehensive protection against over-voltage, under-voltage, over-current, and phase imbalances. It provides an adjustable solution for managing power quality in 3-phase systems, ensuring the safety and reliability of connected equipment.

Key Features

  • Over-voltage Protection: Adjustable range of 230V to 300V, preventing damage from voltage spikes.
  • Under-voltage Protection: Adjustable range of 120V to 210V, protecting systems from low voltage conditions.
  • Over-Current Protection: Adjustable range of 5A to 63A, ensuring circuits are safeguarded from excessive current.
  • Asymmetry Protection: Detects phase imbalance and prevents operational issues.
  • Phase Sequence Protection: Ensures proper phase rotation to prevent equipment damage.
  • Adjustable Timing: Active time and reconnect time can be set for optimal system management.
  • Manual Calibration: Allows for manual calibration of voltage and current for accurate readings and control.

Specifications

  • Rated Power Supply Voltage: AC 230V
  • Rated Frequency: 50/60Hz
  • Maximum Voltage Adjustment Range: 230V~300V
  • Minimum Voltage Adjustment Range: 120V~210V
  • Current Adjustment Range: 5A~63A
  • Phase Unbalance Fault Delay: 10s
  • Overcurrent Fault Delay: 5s~600s
  • Overvoltage Fault Delay: 0s~10s
  • Undervoltage Fault Delay: 0s~10s
  • Voltmeter Accuracy: 1%
  • Insulation Voltage: 450V
  • IP Rating: IP20 (Protection against dust and water ingress)
  • Electrical Life: 100,000 operations
  • Mechanical Life: 1,000,000 operations
  • Operating Temperature: -5°C to +50°C
  • Storage Temperature: -40°C to +55°C
  • Installation: Compatible with 35mm DIN rail for easy installation.

The CNC YC9VA-3 4Pole 3 Phase Voltage and Current Protector is an essential protection device for industrial and commercial applications where maintaining stable power supply is crucial. It ensures long-lasting protection for electrical systems and enhances operational reliability.

Parameter Data
Rated power supply voltage AC230V
Rated frequency 50/60Hz
Maximum voltage adjustment range 230V~300V
Minimum voltage adjustment range 120V-210V
Range of adjustment of the maximum current 5A~63A
Deviation 2%
Delay time of phase unbalance fault 10s
Delay time of overcurrent fault 5s~600s
Delay time of closing 5s~600s
Delay time of overvoltage fault Os~10s
Delay time of undervoltage fault Os 10s
Lag voltage of overvoltage and undervoltage OV~15V
Voltmeter accuracy 1%
Rated insulation voltage 450
Output contact 30N
Protection IP20
Pollution 3
Electrical life 100000
Mechanical life 1000000
Altitude ≤2000m
Operating temperature -5°C~+50°C
Relative humidity 50% at 40°C(non-condensation)
Storage temperature -40°C~+55°C
Installation 35mm DIN rail
